Next-Gen Hardware
While the Pilot edition is being manufactured for early adopters, The next hardware revision, code named Arpeggio is nearly complete
-
Consolidated Anchor Modules
Rectangular CDPRs need four pull points, but since the lines have such low stretch and friction, the motors don't actually need to be at the corners. Arpeggio anchors merge pairs of anchors into single components to save cost and complexity, while using eyelets in the adjacent corners to maintain ideal geometry. Install time is decreased, and half as many outlets are required.
-
High-Torque BLDC Motors
Moving away from steppers, the next generation utilizes Brushless DC (BLDC) motors. They provide a roughly 8x increase in torque and a more favorable torque curve. We are targeting a payload capacity of around 4kg.
-
Versatile Mounting
Stringman's new anchors have a mounting block that can be changed out for various types of mounting methods including studs, tripods, and drop ceiling T-bars.
